Pipe Standards

Nominal Pipe Size

Outside Diameter

5 S

10 S

SCH 10

SCH20

(inches)

(mm)

WALL THICKNESS

WEIGHT

WALL THICKNESS

WEIGHT

WALL THICKNESS

WEIGHT

WALL THICKNESS

WEIGHT

(mm)

(kg/m)

(mm)

(kg/m)

(mm)

(kg/m)

(mm)

(kg/m)

1/8''

10.30

-

-

1.24

0.282

-

-

-

-

1/4''

13.70

-

-

1.65

0.499

-

-

-

-

3/8''

17.10

-

-

1.65

0.640

-

-

-

-

1/2''

21.30

1.65

0.814

2.11

1.017

-

-

-

-

3/4''

26.70

1.65

1.038

2.11

1.303

-

-

-

-

1''

33.40

1.65

1.316

2.77

2.131

-

-

-

-

1 1/4''

42.20

1.65

1.681

2.77

2.744

-

-

-

-

1 1/2''

48.30

1.65

1.934

2.77

3.168

-

-

-

-

2''

60.30

1.65

2.431

2.77

4.003

-

-

-

-

2 1/2''

73.00

2.11

3.757

3.05

5.359

-

-

-

-

3''

88.90

2.11

4.600

3.05

6.577

-

-

-

-

3 1/2''

101.60

2.11

5.273

3.05

7.551

-

-

-

-

4''

114.30

2.11

5.946

3.05

8.524

-

-

-

-

5''

141.30

2.77

9.639

3.40

11.778

-

-

-

-

6''

168.30

2.77

11.518

3.40

14.084

-

-

-

-

8''

219.10

2.77

15.053

3.76

20.339

-

-

6.35

33.936

10''

273.00

3.40

23.026

4.19

28.293

-

-

6.35

42.534

12''

323.90

3.96

31.826

4.57

36.659

-

-

6.35

50.653

14''

355.60

3.98

35.154

4.78

42.124

6.35

55.710

7.92

69.171

16''

406.40

4.19

42.334

4.78

48.224

6.35

63.813

7.92

79.278

18''

457.20

4.19

47.681

4.78

54.324

6.35

71.916

7.92

89.384

20''

508.00

4.77

60.298

5.53

69.800

6.35

80.019

9.52

119.208

22''

558.80

4.77

66.385

5.53

76.857

6.35

88.122

9.52

131.356

24''

609.60

5.54

84.064

6.35

96.226

6.35

96.226

9.52

143.505

26''

660.40

-

-
